In cylindro processui instrumenti hoc tempore designato maxime includit fistulam ferream automatariam machinis secandis, machinis exercendis fistulam duplicem finem latae, et gas dioxidum carbonis machinis glutinis automati munitis, etc.
(1) Support Roller Pipe cutting MachineModel: CO160
Tibia applicabilis diametri (diametri exterioris) range: 89, 108, 133, 159, 194, 219mm
Locus murus fistulae crassitudine range: 3~ 12mm
Maximam longitudinem fistulae rudis materiae: 9000mm
Praecipua machina altitudo centri: 1000mm
Fusum velocitatem: 50~ 250r/min
Celeritas pascens: 0~60mm/min
Secans longitudo range: 180mm~2600mm
Cum secatio longitudinis 800mm sit, error secans longitudinis ±0.2mm est;
cum longitudo 800mm excedit, error pervenit ad subtilitatem IT9
Parallelismus tolerantiae incisae fines: level 9
Secans et relucens asperitas: 6.3~ 12.5(2).
Support Roller Double-head Automatic Wedding MachineInput Power: Three-phase 380V 50Hz
Filum applicabile glutino: Ф1.2~1.6mm
Gas clypeus fluunt rate: 10~25L/min
Weldable workpiece longitudo: CCC ~ 2600mm
Weldable workpiece diameter: 89~Ф219
Fusum celeritatem: 0 ~ 10rpm
Plaga cylindrica clampns: 200mm
Adjustable glutino fax angulus: ±20°
Machina amplitudo: 5100x880x1700mm
